Fumecare FC Ceiling Unit Module (CFU Series)
The Fumecare FC Ceiling Unit Module (CFU Series) is an economical, ceiling-mounted clean air and fume extraction system designed for laboratories requiring flexible, ductless air filtration. Ideal for healthcare, research, and forensic environments, this unit provides effective airborne contaminant control without the need for costly ducted infrastructure.
Mounted overhead, the module captures airborne contaminants and passes them through high-efficiency filtration before safely recirculating clean air back into the laboratory. This design supports improved indoor air quality while maintaining clear, unobstructed workspace below.
Flexible Clean Air or Fume Extraction Configuration
The FC Ceiling Unit Module can be configured for either clean air supply or fume extraction, making it a versatile solution across a wide range of laboratory applications.
- Configurable for air supply or extraction
- Suitable for general laboratory use
- Ideal for retrofits and existing facilities
- Supports localised air quality improvement
Advanced Filtration with HEPA and Carbon Options
The system incorporates high-performance filtration to remove particulates, vapours and airborne contaminants.
- HEPA filtration for particulate removal
- Carbon filtration for chemical fumes and odours
- High-efficiency prefilter (>99.6%)
- Recirculatory airflow system
Harmful fumes are captured and filtered, with clean air safely returned to the laboratory environment.
Ductless Design for Cost Efficiency and Flexibility
The ductless construction eliminates the need for expensive HVAC modifications, making installation simple and cost-effective.
- No ducting required
- Reduced installation costs
- Ideal for upgrades or temporary installations
- Easily repositioned if required
Reliable Performance and Safety Monitoring
Designed for consistent operation, the unit maintains stable airflow and includes safety monitoring features.
- Airflow: 580 m³/hr
- Face velocity: >0.5 m/s
- Low airflow indicator for safety compliance
- Low noise operation (55 dBA)
- Variable speed DC fan
Robust Construction for Laboratory Environments
Built for durability and long-term performance, the unit features a robust industrial design.
- Epoxy-coated mild steel construction
- Ceiling-mounted configuration
- Designed for suspension via hanging rods
- Compact, space-saving footprint
Applications
- Laboratory environments
- Healthcare and hospital facilities
- Forensic laboratories
- Clean air supplementation zones
- Chemical handling areas
- Retrofit IAQ improvementshttps:
